Product Details:
|
| Features: | Projection Up To 500" | Brightness: | 20000 Lumens |
|---|---|---|---|
| Purpose: | Videos Mapping | Type: | 3LCD Laser Technology |
| Contrast Ratio: | 3000000:1 | Screen: | Up To 500" Super Big |
| High Light: | Sdi Full Hd Projector,3lcd Full Hd Projector,Hdmi 20000 Lumen Laser Projector |
||
3lcd Sdi Hdmi Dvi Wuxga Full Hd Projector 20000 Lumens Laser Projector
1. Scope of application for DL13U ,Large Venue Laser Projector
1. outdoor advertising display,3d mapping projection
2. 7*24 hrs no-stop working .
3. large cinema/theatre
4. Bars, KTV night clubs, concerts and churches
5. Daytime education (big multimedia classroom)
6. daytime company or business multi-media presentation(conference)
7. Training course, Houtdoor show projector
8. other situation need huge projection size enough brightness high lumens project projector
2. Technical parameters for DL13U Large Venue projector
| Display Technology | 3LCD | |
| Native Resolution | WUXGA 1920* 1200 | |
| Max. Video Input | 4K | |
| Brightness | 20000 ansi Lumens | |
| Contrast | 100000:1 Contrast Ratio | |
| Fan Noise | As low as 27 dBa | |
| Aspect Ratio | 16:10 Native,16:9 Compatible | |
| Projection Method | Front, Rear,Ceiling,Table Top;Projection Image support horizontal and vertical flip | |
| Weight | 30 kg | |
| I/O Connectors | Inputs: | VGAx1; Y, Pb/Cb, Pr/Crx1; S-Videox1; HDMIx2; DVIx1; CVBSx1; HDBaseTx1; IRx1; RS232x1; RJ45x1,SDIx1 |
| Maximum Resolution | 4K via HDMI Terminal | |
| Computer Compatibility | Standard 1080P(1920x1080),WSXGA+,WXGA+,WXGA(1280x800/1280x768),UXGA, SXGA, XGA, SVGA, VGA, Mac… | |
| Video Compatibility | PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080P, 720p) | |
| Displayable Colours | 1.07 Billion | |
| Power Lens Shift: | U/D -40%to 120%; L/R 20% | |
| Lens Optional: | Short throw lens,Long throw lens,Ultra-short focal-lens,360-degree wide-angle lens,Spherical Fisheye lens | |
| Throw Ratio | According to the lens | |
| Projection Screen Size | According to the lens | |
| Projection Distance | According to the lens | |
| Lamp Type/Lamp Life | 850W Roller type laser light source, 20000 hours life | |
| Keystone Correction * | ± 50°up&down,± 30°L&R, | |
| Dimensions (W x D x H) | 560x558x295 mm | |
| Remote Control | Full function remote with direct source selecting | |
| Power Supply | 100-240V, 50-60Hz | |
| Power Consumption | 1088W | |
| Operating Conditions | 5°C - 40°C, Max. Humidity 85%, Max. Altitude 3000m | |
| Uniformity | 90% | |
| Standard Accessories | AC Power Cord,VGA Cable, Remote Control,Quick Start Card,CD User Manual, Warranty Card | |
| Optional Accessories | Ceiling Mount Kit, Additional Ultra long Cable | |
| Guarantee | Projector 3 years | |
3.Outstanding features for EL-M906U projector
1, Perfect Image quality by 3LCD technology ,2 color wheels ,WUXGA 1920* 1200 native resolution.
2,Newly adopted Roller type laser light source 480W lamp brings super effects of high brightness and contrast ratio along with extended lamp life20000 hrs.
3,High adjustable contrast ratio 100000:1 brings super visual effects of sharpness and high definition.
5,7*24 hrs no-stop working
6,Mutiple lenses options for diferent venues
Push the button, rotate the lens and it is goes off directly from the projector, easy and swift for lens
replacing,More than 6 Optional wide-angle and telephoto lenses .
7,Fine and closely woven dust-proof filter
Easy to change Hyprid filter protects the projectorfrom fog, dust and smoke .
8,360° projection for multi-media scenarios
DP9100 is able to project 360° vertically which is applied to muti-media scenarios.
9,Prioritized LAN network control and Video
Through the LAN management and control, the user can easily operate every one of or some of
projectors in the system formed by connecting two or more units together.
10,Motored vertical and horizontal lens shift
Motored lens and focus functionalities are incorporated in DP9100 series. Vertical and horizontal
image shift can be easily
carried out by motored lens instead of moving the projector manually.
Zoom in and out of the image can be easily carried out by remote control even if the projector is
installed extemely high.
Motored zoom and focus for fine tune and remote control: even installed way out of reach, the
projector is able to be operated
for adjustments in distance.
Lens shift: vetical(+/=50%)and horizontal (+/=10% max) shifts make operation directly visible for
installation on site.
11,Adjustable cooling time, this newly developed technology embedded realizes the setting of cooling
time arranging from 3 minutes to 1 minute according to the user’s demands.
12.Multiple connectivities
BNC is suitable for long distance stable signal transmission, a perfect match with top survailance and
acoustic devices.
Component terminals are designed for business occasions. Compatibility with YPbPr input and output
makes home cinema and entertainment easily available.
Through the port, network operation and control is conveniently managed. A computer is able to control
all the projectors within the LAN, only if the user enters the corresponding IP in IE address bar.
HDMI, the best choice for film display, can transimit audio and vedio signals without compression.
