FL-S3206U 32000 Lumens 3LCD Laser Engineering Projector WUXGA 1920x1200 360 Degree Large Venue

Place of Origin: Shenzhen, China
Brand Name: Flyin
Certification: CB IEC 62368-1:2018, cTUVus, FCC ID, CE-RED, CE-ERP, EMC Class A
Model Number: FL-S3206U
Minimum Order Quantity: 1 Piece
Price: USD 22000 / Piece
Packaging Details: 34 x 54 x 13.5 cm export carton
Delivery Time: 5-8 work days
Payment Terms: L/C,D/A,T/T,Western Union,
Supply Ability: 500 Pieces per Month
Inquiry Now
Get A Quote
Specifications
Highlight Features

32000 Lumen 3LCD Laser Projector

,

Motorized Zoom Lens Shift

,

Edge Blending 360 Degree Projection

Brightness:
32000 Lumens
Display Technology:
3LCD Laser
Native Resolution:
WUXGA (1920x1200)
Contrast Ratio:
3000:1
Light Source Lifetime:
30000 Hours
Optional Lenses:
6
Projection:
360 Degree
Max Screen Size:
500 Inch
Color Depth:
1.07 Billion Colors
Standby Power Consumption:
0.5W
Interfaces:
2x HDMI 1.4 In, 1x HDMI 1.4 Out, HDBaseT, DVI-D, VGA, RJ45, DMX512, 3G-SDI (optional)
Certification:
CE, FCC, ROHS
Light Source:
Dual-Color Laser (Blue + Red)
Brightness Uniformity:
90% (JBMA Standard)
Laser Lifespan:
20000h Normal / 30000h ECO
Throw Ratio:
1.24-2.01:1 (@100 Inches)
Lens Shift:
Vertical ±65%, Horizontal ±25%
Power Consumption:
1920W Max / 1555W ECO
Noise Level:
41dB
Net Weight:
38.7KG
Gross Weight:
46KG
Dimensions:
655 X 311 X 558 Mm
OSD Languages:
26 Languages
Control:
LAN, Crestron, AMX, PJ Link
Product Description

FL-S3206U 32000 Lumens 3LCD Laser Projector

The Flyin FL-S3206U is a brand-new 3LCD laser projector engineered for large venue applications, delivering extraordinary 32,000 lumens brightness to redefine professional projection standards.

Extreme Brightness & Light Source

  • 32,000 ANSI lumens (full power mode)
  • Dual-color laser light source (blue + red) for superior colour performance
  • Ultra-long laser lifespan: 20,000 hours (normal) / 30,000 hours (ECO)

Professional Image Quality

  • WUXGA (1920 x 1200) native resolution
  • 3LCD liquid crystal display technology
  • 3000:1 contrast ratio
  • 90% brightness uniformity (JBMA standard)
  • Native 16:10 aspect ratio, compatible with 4:3 / 16:9 / 16:6

Flexible Installation

  • 1.24-2.01:1 throw ratio (@100 inches)
  • Motorized zoom and focus
  • Lens shift: vertical ±65%, horizontal ±25%
  • 6-corner geometry correction plus pincushion/barrel correction
  • 360° projection capability

Comprehensive Connectivity

  • 2x HDMI 1.4 input + 1x HDMI 1.4 output
  • HDBaseT, DVI-D, VGA
  • RJ45 network control (Crestron 1.0 compatible)
  • DMX512 control interface
  • Optional 3G-SDI

Intelligent Control

  • 26-language OSD menu
  • LAN control / AMX discovery / PJ Link
  • Auto setup / signal search / auto PC detection
  • Edge blending and lens position memory

Technical Specifications

ParameterSpecification
Brightness32,000 Lumens
ResolutionWUXGA (1920 x 1200)
Contrast Ratio3000:1
Light SourceDual-Color Laser (Blue + Red)
Laser Lifespan20,000-30,000 hours
Throw Ratio1.24-2.01:1
Power Consumption1920W (Max) / 1555W (ECO)
Noise Level41dB
Weight38.7KG (Net) / 46KG (Gross)
Dimensions655 x 311 x 558 mm

Ideal Applications

Large conference halls and auditoriums, theaters and performing arts centers, museums and exhibition halls, cinemas and large-scale events, university lecture halls and sports venues.

FAQS

Q1. Compare DLP vs LCD projectors - which is better?

Both technologies have their strengths. The FL-S3206U adopts 3LCD liquid-crystal technology, which reproduces smooth, accurate colour without the DLP “rainbow effect” and maintains 90% brightness uniformity. That combination makes it especially reliable for large venues and multi-projector edge-blending arrays.

Q2. Best projectors for gaming - is this model a good choice?

Yes. With native WUXGA (1920×1200) resolution, HDMI 1.4 input/output, HDBaseT and low-latency signal processing, the FL-S3206U delivers sharp, detailed images for high-motion content, while its 32,000 ANSI lumens keep the picture vivid even on very large screens.

Q3. Short throw vs long throw projectors - which do I need?

Short-throw units suit tight rooms, while long-throw units suit large venues and big screens. The FL-S3206U uses a 1.24–2.01:1 throw ratio with motorized zoom/focus and six optional lenses (lens shift V±65% / H±25%), so it adapts flexibly to auditoriums, theatres and domes instead of being locked to one mounting distance.

Q4. Projector screen types - which screens are compatible?

The FL-S3206U works with fixed-frame, portable, front/rear screens and gauze/mesh or water screens. Its 6-corner geometry correction, pincushion/barrel correction and built-in edge blending also allow direct projection onto curved, irregular or non-screen surfaces such as building facades and domes.

Q5. Outdoor movie projector setup - how do I set up an outdoor show?

For outdoor use, brightness and reliability are critical. The FL-S3206U’s 32,000 ANSI lumens resist ambient light, while its sealed dust-proof filter-free design, 0–45°C operating range and high-altitude support up to 3,640 m allow stable 7×24 continuous operation. DMX512 and HDBaseT support easy integration with media servers and stage-lighting systems.

Q6. Compare 1080p and 4K projectors - do I need 4K?

For large-venue and mapping projects, brightness and colour consistency usually matter more than pixel count. The FL-S3206U offers native WUXGA (1920×1200) resolution — above standard 1080p — combined with 32,000 lumens and 3,000,000:1 contrast, delivering high perceived detail across very large images where a lower-brightness 4K unit would struggle.

Q7. Popular projector brands - which brand can I trust?

For engineering-grade installations, choose brands with proven large-venue hardware and OEM/ODM support. The FL-S3206U is a Flyin professional engineering laser projector, backed by CB IEC 62368-1, cTUVus, FCC, CE-RED, CE-ERP and EMC Class A certifications, and supports project solutions, sample testing and OEM customization.

Q8. Projector brightness vs contrast ratio - which matters more?

For large venues and outdoor shows, brightness is the deciding factor: without enough lumens, contrast is lost to ambient light. The FL-S3206U pairs an exceptional 32,000 ANSI lumens with a 3,000,000:1 contrast ratio, so both punch and depth are preserved even in bright, large-scale environments.
