High-performance 3LCD laser projector designed for large venue applications including churches, conference halls, classrooms, and exhibition spaces.
| Display Specifications | |
|---|---|
| Display Technology | 3LCD Liquid Crystal Display |
| Native Resolution | WUXGA (1920 x 1200) |
| Brightness | 6000 ANSI Lumens |
| Contrast Ratio | 5,000,000:1 |
| Aspect Ratio | Native: 16:10, Compatible: 4:3/16:9 |
| Uniformity | 90% |
| Light Source | |
| Light Source Type | Laser |
| Lifetime (Normal Mode) | 20,000 hours |
| Lifetime (ECO Mode) | 20,000 hours |
| Lifetime (ECO2 Mode) | 30,000 hours |
| Lens System | |
| Lens Vendor | RICOH Lens |
| Throw Ratio | 1.2 (wide) - 2.0 (tele) |
| Zoom Ratio | 1.6x |
| Screen Size | 30-300 inches |
| Lens Shift | Vertical: +60% to 0%, Horizontal: ±29% |
| Connectivity | |
| HDMI 1.4B | 2 inputs |
| VGA | 1 input, 1 output |
| USB | 1x USB-A, 2x USB-B |
| Network | RJ45 (Display & Control) |
| Audio | 1x Audio in, 1x Audio out |
| Control | RS232, RJ45, USB-B (for upgrade) |
| General Specifications | |
| Speaker | 16W x 1 |
| Noise Level | 38dB (Normal), 30dB (ECO1), 28dB (ECO2) |
| Dust Filter | Included |
| Filter Lifetime | 8,000 hours |
